Flow - Temperature
Differential pressure/temperature sensor and transducer

Part of the ITES-system, but can be used seperately.

Measured parameters:

  • Differential pressure 0,01..10,00 hPa (1...1000Pa)
  • Static pressure 400..1300hPa
  • Temperature (type K thermocouple) 0..500°C
  • Power supply 24VDC
  • Analog output 4..20mA on Harting plug
Differential pressure/temperature sensor and transducer
  • Differential pressure 0,01..10,00 hPa temperature compensated, precision +/-0,01 hPa
  • Static pressure 400..1300hPa, precision 0,2% FS
  • Temperature (type K thermocouple) 0..500°C, precision 0,4% FS
  • Power supply 24VDC (external)
  • Analog outpout 4..20mA on Harting-plug
  • Housing: Aluminum
  • Dimensions 200 x 60 x 100 mm
  • Weight ~1 kg
Differential pressure/temperature sensor and transducer
Differential pressure/temperature sensor and transducer
Differential pressure/temperature sensor and transducer
S-pitot with/without thermocouple

S-pitot tube with or without integrated thermocouple, in accordance to ISO 10780: 1994 (E), material stainless steel, titanium or special steel for high temperatures (max. 1000°C). Standard diameter 30mm, other diameters (min. 10mm) at demand. Ask for our special extra-robust version with lifting hook, protection cap for pitot tip and protection for thermocouple.

DKD / DAkkS calibration, equal to NIST / ISO 17025 , possible.

S-pitot with/without thermocouple
S-pitot with/without thermocouple
S-pitot with/without thermocouple
S-pitot with/without thermocouple
Pitot tubes
Prandtl L-pitot tubes
Pitot tubes
Pitot tubes
Pitot tubes
Pitot tubes
Cylindrical pitot tubes
Cylindrical pitot tubes in stainless steel, titanium or special steel, diameter 20mm
Cylindrical pitot tubes
Cylindrical pitot tubes
Cylindrical pitot tubes
Cylindrical pitot tubes
Extensible pitot tubes
Extensible pitot tubes with L- or S-tip, with or without thermocouple. For flow measurements in bug ducs. Length up to 6000mm.
Extensible pitot tubes
Diameter 40mm other diameters at demand Material stainless steel (600°C) or fetherlight titanium (400°C)
Extensible pitot tubes
Extensible pitot tubes
Extensible pitot tubes
Digital differential pressure manometer Greisinger
Different precisions and measuring ranges possible: Measuring range 0 … 19,99 mbar (0…2000Pa) or higher Measuring range -1,00 … 25,00 mbar (-100…2500Pa) or higher, datalogging possible
Digital differential pressure manometer Greisinger
Digital differential pressure manometer Greisinger
Digital differential pressure manometer Greisinger
Digital differential pressure manometer Greisinger
Testo 521 high-precision lmanometer for differential pressure and termperature
Testo 521 manometer for differential pressure, with thermocouple connection, measuring range 0…250Pa and -200…1370°C (type K)
Testo 521 high-precision lmanometer for differential pressure and termperature
Differential pressure Range 0 … 2,5 hPa Precision ±0,5 Pa (0 … 20 Pa) ±(0,5 Pa ±0,5 % v. Mw.) (20,1 … 250 Pa) Resolution 0,01 Pa Ambient pressure 1000 hPa Overload 50 hPa Zero to 0,5 hPa Type K thermocouple Range -200 … +1370 °C Precision ±0,4 °C (-100 … +200 °C) ±1 °C (overig meetbereik) Resolution 0,1 °C General Casing ABS Warranty 2 jaar Measuring interval 0,04 Connection Hose: inner Ø 4 mm outer Ø 6 mm Miscellanious Mains connection and battery recharging in instrument; Automatic recognition of all connected probes; 9 measurement units selectable: mbar, hPa, bar, Pa, kPa, inH?O, mmH?O, torr, psi battery type 9 V (6LR61) Lifespan battery Continuous operation w/ internal pressure sensor: 30 h; With rech. battery: 10 h; With carbon battery: 18 h Dimensions 219 x 68 x 50 mm display type LCD display functions 7 segment display and point matrix display update 2x per second, in fast measurement 4x per second data transfer RS 232 Operating temperature 0 … +50 °C Storage 25.000 values Storage temperature -20 … +70 °C Weight 300 g
Testo 521 high-precision lmanometer for differential pressure and termperature
Testo 521 high-precision lmanometer for differential pressure and termperature
Testo 521 high-precision lmanometer for differential pressure and termperature
Testo 435-4 multifunctional devic
Testo 435-4, multifunctional device with integrated differential pressure, temperature, measuring ranges 0…2500Pa, -200…1370°C (type K), with loggerfunction and usb-datatransfer to pc. Humidity probe and vane measuring probe connectable. IP54
Testo 435-4 multifunctional devic
Testo 435-4 multifunctional devic
Testo 435-4 multifunctional devic
Testo 435-4 multifunctional devic
Digital manometer Special instruments DIGIMA
Digital manometer Special instruments DIGIMA for differential pressure, measuring range +/-19,99 mbar (+/-1999Pa) or higher. Possible with analogue signaloutput 0-1V to connect a datalogger. IP64 Multiple measuring ranges in one instrument
Digital manometer Special instruments DIGIMA
Digital manometer Special instruments DIGIMA
Digital manometer Special instruments DIGIMA
Digital manometer Special instruments DIGIMA
Airflow multifunction manometer
Airflow digital manometer for differential pressure, different types possible with temperature, datalog, humidity probe, …
Airflow multifunction manometer
Airflow multifunction manometer
Airflow multifunction manometer
Airflow multifunction manometer
Hoentzsch robust temperature resistant vane anemometer

Hoentzsch very robust rotary vane anemometer

Extendable and therefore practical for applications in smoke stacks, etc.

Range 0.6 ... 120 m/s (gas)

Cylindrical vane wheel sensor / insertion probe with probe diameter 16 or 25mm.

Probe materials: aluminium, stainless steel or titanium.

Working temperature range up to +500 °C (according to version).

Suitable for fixed and portable measuring of actual flow velocity v [m/s] and flow rate V/t [m³/h, l/min] in clean gases and liquids, briefly also in particle-laden mediums.

Signal evaluation with handheld flowtherm NT, flowtherm Ex, transducer UFA and system units.

Hoentzsch robust temperature resistant vane anemometer

Measuring range 0.6 ... 120 m/s in gases

Pressure resistance up to 10 bar / 1 MPa overpressure

Media temperature -40 ... +500 °C

Media gases / liquids

IP protection type IP65 (cable side)

Type of protection ATEX category 2G (zone 1), (optional)

Attachments

Hoentzsch robust temperature resistant vane anemometer
Hoentzsch robust temperature resistant vane anemometer
Hoentzsch robust temperature resistant vane anemometer
Jacket thermoelement
Jacket thermoelement, NiCr-Ni (Type K), Class 1, -220 °C...+1150 °C, different lengths, diameters and connections possible We deliver only uses class 1 thermocouple material acc. to DIN EN 60584 Also in our delivery program:Type N, J, L, T, S, B, C, and more
Jacket thermoelement
Diamters available 0.15mm, 0.25mm, 0.50mm, 0.75mm, 1.00mm, 1.50mm, 1.60mm, 2.00mm, 3.00mm, 3.20mm, 4.50mm, 6.00mm, 8.00mm Temperature range -220 °C...+1150 °C (Inconel sheet)
Jacket thermoelement
Jacket thermoelement
Jacket thermoelement
Pyrometers
Pyrometers to measure temperatures >1000°C according to VDI / VDE 3511, page 5 up to 1200°C or according to IFRF and VDE (up to 1600°C)
Pyrometers
Cooled pyrometer outer diameter Ø50mm Material: stainless steel of super-light titanium Length: max. 6000mm Attention: Above 1200°C a thermocouple type S is needed
Pyrometers
Pyrometers
Pyrometers
Thermocouple with stainless steel protection tube Ø10mm
Thermocouple type K, class 1 according EN60584 Diameter 1,5mm Protection tube Ø10mm perforated for a fast response time Compansating cable connected teflon/stainless steel braiding/teflon Lengths 1,2 or 3m or to your demand
Thermocouple with stainless steel protection tube Ø10mm
Thermocouple with stainless steel protection tube Ø10mm
Thermocouple with stainless steel protection tube Ø10mm
Thermocouple with stainless steel protection tube Ø10mm
Thermocouple 3/6mm with PTFE coating

Inconel thermocouple Ø3mm

with enlargement 6mm for Swagelok® or GL14 cap and seal

Thermocouple 3/6mm with PTFE coating

Compensation cables:

Teflon / stainless steel braiding / teflon : very robuste, Tmax 200°C

Glass silk / glass silk / stainless steel braiding : Tmax 400°C

PVC / stainless steel braiding / PVC: Tmax 105°C

Teflon / silicone


Connectors:

Miniature connector (flat pins) (optional strain relief)

Standard connector (round pins) (optional strain relief)

Thermocouple 3/6mm with PTFE coating
Thermocouple 3/6mm with PTFE coating
Thermocouple 3/6mm with PTFE coating
Explosion proof thermometer

P700-EX explosion proof thermometer

Type for meas­uring in explo­sion endangered areas (temper­ature range -200°C...+850°C). EX-mark: EEX ib IIB T4

Product features

  • USB interface
  • Optional DE-Graph Windows Software for graphic andtabular documentation
  • High measuring accuracy
  • Integrated calibration function for simple compensation of sensor tolerances
  • Physical 1-point, 2-point or 3-point calibration function
  • Measuring channels are freely assignable
  • Recording maximum, minimum, hold and average values
  • Integrated sensor holder for one hand operation
  • Mains operation possible
  • Differential temperature displa
Explosion proof thermometer

Inputs 1-channel, Pt100
Meas­uring range
Pt100 -200°C...+850°C
Accuracy
Pt100 ±0,1°C from -100°C...+200°C
0,1 % remaining range
Resol­u­tion 0,1°C remaining range
EX-mark EEX ib IIB T4
Connectors DIN 8-pole
Working temper­ature 0°C...+40°C
Display 2-line LCD
Housing plastic
Dimen­sions

200 x 93 x 44 mm (LxBxH)

Weight

600 g

Power supply 9 V battery
Batterie life appr. 20 h
Explosion proof thermometer
Explosion proof thermometer
Explosion proof thermometer

Fitting probes (only Pt100):

Pt100, Kl. 1/10 DIN -200...+450 °C 300 x 3,0 mm
Pt100, Kl. 1/10 DIN -200...+450 °C 300 x 6,0 mm
Pt100, Kl. 1/3 DIN -200...+450 °C 150 x 3,0 mm
Pt100, Kl. 1/3 DIN -200...+450 °C 300 x 1,5 mm
Pt100, Kl. 1/3 DIN -200...+450 °C 300 x 3,0 mm
Pt100, Kl. 1/3 DIN -200...+450 °C 300 x 6,0 mm
Pt100, Kl. B -50...+350 °C 150 x 4,0 mm
Pt100, Kl. B -40...+200 °C 35x12mm
Pt100, Kl. B -40...+300 °C 150 x 6 mm Ø
Pt100, Kl. B -50...+250 °C 250 x 4 mm Ø
Pt100, Kl. B -50...+350 °C 150 x 3,0 mm
Pt100, Kl. B -50...+350 °C 300 x 3,0 mm
Pt100, Kl. B -50...+350 °C 500 x 3,0 mm

Type K Thermocouple with wooden handle

Thermocouple NiCr-Ni (Type K, class 1) Ø3mm, with wooden handle and bend protection

Type K Thermocouple with wooden handle
Type K Thermocouple with wooden handle
Type K Thermocouple with wooden handle
Type K Thermocouple with wooden handle
